12025 dc brushless fan 25mm thickness 3000RPM 12V computer fan with low noise
Frame and Impeller: Metal, Plastic (94V-0),PBT
Bearing Type: Ball bearing
Function Range: FG RD PWM IP58 IP68
Leadwire: Red Wire Positive(+),Black Wire Negative(-)
Operating Voltage: 12V 24V 48V
Tempetature Range: –20℃ to +70℃
Motor: Impedance Protected and Reverse Polarity Protected
Specification
| Model | Bearing Type | Rated Voltage | Operating Voltage | Input Current | Input Power | Speed | Max Air Flow | Max Static Pressure | Noise | Weight |
| Part No. | B.S | VDC | VDC | Amp | Watt | RPM | CFM | m3/min | Inch-H2O | pa | dB-A | g |
| MX12025AB(S/Y)U1 | B.S.Y | 12 | 7.0-13.8 | 0.80 | 9.60 | 3500 | 122.12 | 3.46 | 0.31 | 77.47 | 49.00 | 140.00 |
| MX12025AB(S/Y)H1 | B.S.Y | 12 | 7.0-13.8 | 0.50 | 6.00 | 3000 | 103.92 | 2.94 | 0.24 | 60.51 | 44.00 | 140.00 |
| MX12025AB(S/Y)M1 | B.S.Y | 12 | 7.0-13.8 | 0.40 | 4.80 | 2500 | 86.65 | 2.45 | 0.18 | 44.03 | 39.00 | 140.00 |
| MX12025AB(S/Y)L1 | B.S.Y | 12 | 7.0-13.8 | 0.20 | 2.40 | 2000 | 67.01 | 1.90 | 0.10 | 26.09 | 35.00 | 140.00 |
| MX12025AB(S/Y)U2 | B.S.Y | 24 | 14.0-27.6 | 0.50 | 12.00 | 3500 | 122.12 | 3.46 | 0.31 | 77.47 | 49.00 | 140.00 |
| MX12025AB(S/Y)H2 | B.S.Y | 24 | 14.0-27.6 | 0.40 | 9.60 | 3000 | 103.92 | 2.94 | 0.24 | 60.51 | 44.00 | 140.00 |
| MX12025AB(S/Y)M2 | B.S.Y | 24 | 14.0-27.6 | 0.25 | 6.00 | 2500 | 86.65 | 2.45 | 0.18 | 44.03 | 39.00 | 140.00 |
| MX12025AB(S/Y)L2 | B.S.Y | 24 | 14.0-27.6 | 0.15 | 3.60 | 2000 | 67.01 | 1.90 | 0.10 | 26.09 | 35.00 | 140.00 |
| MX12025AB(S/Y)U4 | B.S.Y | 48 | 28.0-56.0 | 0.40 | 19.20 | 3500 | 122.12 | 3.46 | 0.31 | 77.47 | 49.00 | 140.00 |
| MX12025AB(S/Y)H4 | B.S.Y | 48 | 28.0-56.0 | 0.30 | 14.40 | 3000 | 103.92 | 2.94 | 0.24 | 60.51 | 44.00 | 140.00 |
| MX12025AB(S/Y)M4 | B.S.Y | 48 | 28.0-56.0 | 0.20 | 9.60 | 2500 | 86.65 | 2.45 | 0.18 | 44.03 | 39.00 | 140.00 |
| MX12025AB(S/Y)L4 | B.S.Y | 48 | 28.0-56.0 | 0.10 | 4.80 | 2000 | 67.01 | 1.90 | 0.10 | 26.09 | 35.00 | 140.00 |
Market
We have an experienced and professional team of manufacturing fan. Our product exported to many countries. Our main markets are south Asia,south America, Europe.
“Concentrate on the sevice of customer” is our purpose. We welcome customers, bussiness associations and friends from all part of world.
We hope to meet your cooperation sincerely.
Our company
Founded in 1996 in Shenzhen China, we, Shenzhen Topfan-China Technology Co., Ltd, is professional manufacturer and researcher on dc brushless fans and ac fans. Our products are ISO9000, CE, RoHS and TUV certificated and good sellers both at home and abroad, including European, North American, Asia(Korea and India) and so on. The products, including brushless fans, cross flow fans, blower fans, centrifugal fans, dc brushless motor, shades pole and RC ac fans, are being widely used in the information technology, network communications as well as industrial production equipment, medical equipment, home appliances and others. Based on mutual benefit and development, we always make our biggest efforts to do everything better for our customers
Packing:
Carton box or according to customers demand
Shipment:
1. FOB Shenzhen or HongKong (mass production)
2. DHL,UPS,FEDEX,TNT or any other international express (sample or small quantity)
Delivery Time:
Generally, 500~1000pcs 10 days after confirming the PI
Payment:
T/T and paypal
1. The payment for the high value sample will be charged.
2. The payment for the low value sample is free, but the freight should be paid by you.
Q: Are you trading company or manufacturer ?
A: We are factory.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for but not free
Q: How long is your delivery time?
A: Generally it is 7-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 50% T/T in advance ,balance before shippment.
